- Min. incremental motion 0.05 µm
- Travel ranges 10 and 25 mm
- Nonrotating end piece
- Velocity to 1.2 mm/s
- MTBF >20000 h
Precision-class linear drive
High-resolution linear actuator. Position-controlled DC motors with a gearhead and high-resolution rotary encoders allow for incremental motion and repeatability of just 100 nm. Low-vibration 2-phase stepper motors with gearhead allow for smooth and accurate open-loop positioning.
Extremely low-friction and backlash-free construction. Nonrotating end piece for uniform motion prevents wobble, torque, and wear at the point of contact. Includes flat and spherical end piece for decoupling of lateral and tilt forces. Noncontact limit switches protect the mechanical system. Closed-loop variants with differential encoder driver for a safe position signal transmission at distances up to 10 m.
Precision alignment, motorized alternative for micrometer screws.
Product Change Notification Lable Change M-products
Product Change Notification M-Portfolio Streamlining 2
M-227.10S, M-230.10V, M-230.25V, M-232.17S, M-235.22S, M-235.2VD, M-235.2VG, M-235.52S, M-235.5VD, M-235.5VG
Short Instructions MP122EK
Linear Actuators: M-168 / M-22x / M-23x
User Manual MP102
M-230 High-Resolution Linear Actuator
