Sistemi XY

Stabilità, precisione e dinamica sono cruciali nei campi di applicazione dei sistemi XY di PI. Sono la base per alti volumi di produzione e affidabilità nelle operazioni. PI si avvale delle proprie competenze nel campo dei motori lineari magnetici PIMag® e dei PIglide a cuscinetti ad aria. La produzione industriale e il controllo qualità traggono vantaggio dall'utilizzo dei sistemi XY ad alta capacità di carico e dagli scanner di PI. Per applicazioni di microscopia, ad esempio nel campo della misurazione in tolpologia, la scansione ripetibile e veloce è combinata con la migliore stabilità di velocità, grazie agli stages PILine®. Il loro basso profilo è straordinario in questo campo. La combinazione con stages piezo a flessione li rende molto versatili.

Stages per Metrologia XY

A-351 MGS Gantry System with Linear Motors

Robust Compact Design with Recirculating Ball Bearing Guides for High Load Capacity.
  • The A-351 MGS air bearing hybrid gantry system with linear motors has been designed to maximize throughput for applications that require overhead motion.

A-341 PIglide HGS Hybrid Gantry System

Hybrid Guide Design with Air Bearings and Recirculating Ball Bearing Guides for High Precision with Low Profile.
  • The A-341 gantry system with linear motors and absolute encoders maximizes throughput for applications that require overhead motion.

V-741 High-Precision XY Stage

High Travel Accuracy and Stability, 305 mm × 305 mm Travel Range, Linear Motors

L-741 Precision XY Stage

High Travel Accuracy and Stability, 305 × 305 mm Travel Range

L-738 Precision XY Stage

Clear Aperture, High Travel Accuracy, and Stability

V-738 High-Precision XY Stage

Clear Aperture, High Travel Accuracy and Stability, Linear Motors

U-723 PILine® XY Stage

Compact XY Stage with Ultrasonic Piezo Motors

V-731 High-Precision XY Stage

High Travel Accuracy and Stability, Linear Motor

L-731 Precision XY Stage

High Travel Accuracy and Stability

A-322 PIglide HS Planar Scanner with Air Bearing

XY Positioning System with 1 nm Resolution
  • XY air bearing stage, planar, high performance, travel to 1 m, linear motors, absolute encoder, nanometer precision. For high accuracy automation &amp
  • metrology.

A-311 PIglide IS Planar Scanner with Air Bearing

High-Performance, Compact XY Nanopositioning System
  • Compact XY-nanopositioning system
  • High-precision positioning
  • Low profile
  • Travel ranges up to 300mm × 400mm
  • Load capacity up to 147N

Stages per Microscopia XY e XYZ

U-760 PILine® XY Stage System with Controller and Joystick

Compact, low vibration, low profile
Novità

M-971 Motorized OEM XY Stage

Low Price with High Quantities

U-780 PILine® XY Stage System with Controller and Joystick

Stable, Dynamic, Low Profile

U-751.24 XY Stage with Piezomotors

Low-Profile and Fast, Direct Position Measurement

P-545.xR8S PInano® XY(Z) Piezo System

Inexpensive Nanopositioning System for High-Resolution Microscopy

P-545.xC8S PInano® Cap XY(Z) Piezo System

Capacitive Position Measuring for Super-Resolution Microscopy

M-545 Microscope XY Stage

Compact, Stable, Long Travel Range

Sistemi die movimento XY

Novità

A-352 MGS Large Format Gantry System with Linear Motors

Robust Compact Design with Recirculating Ball Bearing Guides for High Load Capacity.
Novità

X-417 Integrated Multi-Axis System

XY(Z) Positioning System with Controller • Quickly Available
